Toilet Paper Printing Machine - Advanced High-Speed Tissue Converting Solution

Modern tissue paper manufacturing demands precision, efficiency, and versatility. The Toilet Paper Printing Machine from Henan Hengyu Machinery combines industrial-grade performance with intelligent automation to deliver exceptional results. Our HY Series easily handles 1200–3000 mm jumbo roll compatibility while achieving high-speed production at 180–240 m/min. From automatic core feeding to paper break detection, every facet of operations is managed by the PLC intelligent automatic control system. It offers single, double, and edge embossing choices and has a precision perforation system (±3mm) to support the manufacturing of both core and coreless rolls. Backed by a full 1-year quality warranty, this equipment provides enterprise-level tissue converting technology developed for serious manufacturers.

Key Technical Specifications

Why Choose Our Toilet Paper Converting Solution

Enhanced Production Efficiency

Your manufacturing operation needs equipment that maximizes output without compromising quality. This Toilet Paper Printing Machine delivers consistent high-speed performance at 180-240 meters per minute. The automatic PLC control system eliminates production bottlenecks by managing rewinding, perforating, core loading, and sealing simultaneously.

You'll experience reduced downtime through automatic paper-break detection. The system stops instantly when issues occur, protecting your raw materials and preventing waste.

Intelligent Automation Technology

Simple parameter settings are offered by the Human Machine Interface (HMI). Production parameters can be swiftly modified without a great deal of technical expertise. Continuous operation is ensured by automatic core feeding cues. When core replenishment is required, the system alerts operators.

Throughout production runs, roll sizes are kept constant by automatic diameter control. This accuracy guarantees that your final goods consistently satisfy high standards of quality.

Versatile Production Capabilities

This equipment adjusts to the demands of your market, whether you are making coreless or normal cored rolls. The optional reeling stopper reduces material waste by up to 15% and enhances roll edge neatness.

With single, double, or edge embossing options, the embossing system provides versatility. Steel-to-rubber or steel-to-steel solutions help you create unusual designs that define your products. For some uses, airbag-style embossing is an option.

Precision Perforation System

The high-precision screw-type punching mechanism delivers accuracy within ±3mm. Four punching knives provide standard perforation distances of 85-135mm. Two-knife configurations extend this range to 170-260mm.

Custom perforation distances are available to meet unique market requirements. This flexibility helps you serve diverse customer preferences across different regions.

Cost-Effective Operation Benefits

Reduced Material Waste

Independent tension control systems minimize paper breaks during high-speed operation. Your raw material costs decrease when production runs smoothly without interruptions. The automatic trimming function ensures consistent edge quality while optimizing material usage.

Lower Labor Requirements

Automation reduces manual intervention throughout the production cycle. Operators focus on quality supervision rather than repetitive tasks. This efficiency allows you to maintain competitive labor costs while scaling production capacity.

Energy Efficiency

Power consumption ranges from 7.5 to 30 KW depending on your configuration. The equipment operates at 380V 50HZ standard industrial voltage. This efficient design keeps operational costs manageable even during extended production shifts.

Advanced Unwinding and Feeding Systems

Large jumbo rolls are supported steadily by the wallboard-style unwinding stand. Continuous feeding is possible while maintaining production speed thanks to two conventional unwinding stands. Additional stands are optional for businesses requiring extended uptime.

Paper flows smoothly and consistently thanks to pneumatic feeding. The system needs an air supply of at least 0.6 MPa, which you will prepare according to the standards of your facility. This feeding technique lessens tension fluctuations that could have an impact on the quality of the final product.

Comprehensive Quality Assurance

Every Toilet Paper Printing Machine undergoes rigorous testing before shipment. Our 1-year warranty covers manufacturing defects and non-human damaged parts. You'll receive free replacement components during the warranty period.

The quality guarantee reflects our confidence in equipment durability. With proper maintenance, your machine will deliver reliable performance for many years beyond the initial warranty coverage.

Complete Business Support

Henan Hengyu offers tissue paper makers complete beginning options in addition to machinery. We help you with machine configuration, production planning, and market research. Technical training guarantees that your operators produce at their best as soon as possible.

Over 95% of clients are able to effectively complete setup thanks to installation support, which includes remote supervision. Production advice helps you fine-tune operations for maximum efficiency. Marketing recommendations help you present your products in a competitive manner.

Frequently Asked Questions

Q: How much capital is needed to start a small-scale tissue paper processing plant?

A: Starting a small-scale operation typically requires approximately US$7,500–10,000. This covers basic equipment, raw materials, and installation. Semi-automatic configurations have lower initial costs, while fully automatic lines require larger budgets but offer better long-term efficiency.

Q: What kind of factory space is needed?

A: You'll need industrial electricity with stable power supply meeting equipment requirements. The space must accommodate machinery, raw material storage, finished goods, and safe operating areas. Adequate factory conditions ensure production efficiency and product quality.

Q: How many employees does a tissue paper processing plant need?

A: Staffing depends on your production line type. Semi-automatic lines require more manual operation and labor. Fully automated systems need fewer operators since equipment handles most processes automatically.

Q: What is the difference between semi-automatic and fully automatic production lines?

A: Semi-automatic lines suit smaller operations with limited budgets but require more manual intervention. Fully automatic lines handle feeding, cutting, folding, and packaging independently, offering higher efficiency and lower long-term operating costs despite greater upfront investment.

Q: What equipment is needed to open a small tissue paper processing plant?

A: Basic equipment includes an auto toilet paper machine with embossing unit, auto/manual cutting machine, and auto/manual packing machine. You can select semi-automatic or fully automatic combinations based on your production scale and budget.
